To repair a wood split caused by a screw, even in thin teak, back the screw out, degrease the crack with acetone, work glue into it (thin CA glue for a hairline crack, slow-cure epoxy for anything wider or anything that lives outdoors), clamp it gently until cured, and re-drill a correctly sized pilot hole before the screw goes back in. With teak, the degreasing step matters as much as the glue choice, because its natural oils are why so many of these repairs let go. Below, the repair is matched to the size of the split, followed by pilot hole sizes that keep it from happening again.
Why the Screw Split the Wood
A wood screw is a wedge. Its shank and threads push fibers aside as it goes in, and thin stock has too little wood around the hole to absorb that pressure, so the fibers part along the grain. Common triggers:
- No pilot hole, or a softwood-size pilot in a hardwood.
- A screw too close to the end or edge of the board.
- A flat-head screw driven without a countersink, so the tapered head acts as a second wedge.
- No clearance hole in the top piece, so the threads grab both boards and force them apart.
- Overdriving with an impact driver.
Teak adds its own complications. It is moderately hard, about 1,000 to 1,155 lbf on the Janka scale, it contains silica that dulls drill bits quickly, and its oily surface resists most glues unless it is cleaned right before gluing.
Assess the Split First
Remove the screw and press the split closed with your fingers or a clamp. Note whether it closes completely, how wide it is when relaxed, whether it runs out the end of the board, and whether any wood is missing. Those four observations decide the repair.
Repair Options by Split Size
| Split condition | Best adhesive and method | Clamping | Wait before re-drilling |
|---|---|---|---|
| Hairline, closes fully, under about 1/32 in | Thin (water-thin) CA glue after an acetone wipe | Light pressure, optional | About 1 hour |
| Open up to about 1/8 in, closes under a clamp | Slow-cure epoxy; a waterproof PVA can work indoors on non-oily woods | Snug, not crushing | Overnight; 24 hr for slow epoxy |
| Wider than 1/8 in, or will not close without strain | Epoxy thickened with wood flour, or a matching wood sliver glued in | Hold position only | 24 hr |
| Split through the hole, hole now stripped | Glue the split first, then epoxy a hardwood dowel or plug into the enlarged hole | Clamp the split; dowel needs none | 24 hr, then drill a new pilot in the dowel |
| Split runs the full length or the part is structural | Epoxy plus reinforcement: spline, butterfly key, or backer block | Cauls to keep it flat | 24 hr |
Sources disagree on how durable CA glue is on oily woods over the long term. For anything outdoors, on a boat, or under load, epoxy is the safer choice.
Why Teak Must Be Degreased
Teak’s oily extractives form a weak boundary layer between glue and wood, and Forest Products Laboratory research notes that solvent-wiping oily woods improves bond strength. CA glue is especially sensitive because the mild acids in plant oils inhibit its cure. The catch is that oil migrates back to the surface, so timing matters:
- Wipe with acetone on a clean white cloth, turning to a fresh section with every pass, until the cloth comes away clean.
- Let the acetone flash off, which takes a minute or two.
- Apply glue within about 15 minutes. Do not degrease the day before.
- For a split you cannot wipe inside, flood it with acetone from a syringe or small brush, flex it gently, and let it evaporate fully before gluing.
Acetone is highly flammable and its vapor is heavier than air. Work with ventilation, away from pilot lights and sparks, and wear nitrile gloves and eye protection.
Hairline Split: Thin CA Method
- Degrease as described above.
- Place a drop of thin CA at one end of the split and let capillary action draw it in. Flexing the piece slightly, or levering the split open and closed with a toothpick, helps it run deeper.
- Keep adding drops until the split stops absorbing glue.
- Press closed with light clamp pressure for a minute. CA can darken surrounding wood, so keep it off the show face and remove squeeze-out by sanding once hard.
- Sand flush with 180 to 220 grit.
Wider Split: Epoxy Method
- Cover clamp jaws and cauls with packing tape or wax paper.
- Ease the split open a hair with a thin blade, taking care not to extend it.
- Degrease inside the split and on the surrounding surfaces.
- Mix a slow-cure epoxy. Work unthickened epoxy into the split first so it wets both faces, then add thickened epoxy if there is a gap to fill.
- Remove the blade and clamp just snug. Over-clamping squeezes epoxy out and starves the joint.
- Scrape off squeeze-out once it turns rubbery, and leave the clamps on for the full labeled cure, typically 24 hours for slow formulas.
- Sand flush and refinish, wiping the teak with acetone again before any oil or varnish.
Uncured epoxy can cause skin sensitization with repeated contact, so wear gloves throughout.
Pilot Hole Sizes to Prevent a Repeat
| Screw gauge | Major diameter | Softwood pilot (pine, cedar) | Hardwood pilot (teak, walnut, cherry) | Very dense wood, brass screws, or near an end | Clearance hole in top piece |
|---|---|---|---|---|---|
| #4 | 0.112 in | 1/16 in | 5/64 in | 3/32 in | 1/8 in |
| #6 | 0.138 in | 5/64 in | 3/32 in | 7/64 in | 9/64 in |
| #8 | 0.164 in | 3/32 to 7/64 in | 7/64 to 1/8 in | 1/8 in | 11/64 in |
| #10 | 0.190 in | 7/64 to 1/8 in | 1/8 to 9/64 in | 9/64 to 5/32 in | 3/16 in |
| #12 | 0.216 in | 1/8 to 9/64 in | 5/32 in | 5/32 to 11/64 in | 7/32 in |
Published charts differ by about 1/64 inch, so drill a test hole in scrap of the same species. If the screw squeaks, binds, or the scrap cracks, go up one size; if it strips out easily, go down one.
Other Habits That Stop Splits
- Respect edge and end distance. A common rule is at least 3 screw diameters from an edge (about 1/2 inch for a #8) and 5 to 10 diameters from an end (roughly 1 to 2 inches). Always pre-drill near ends, even in softwood.
- Drill a clearance hole through the top piece so only the bottom piece carries threads.
- Countersink flat-head screws so the head seats without wedging.
- Use sharp bits. Teak’s silica dulls high-speed steel fast, and a dull bit burnishes and heats the hole.
- Wax the threads with paraffin or beeswax to cut driving torque, and drive the last turns by hand or with the drill clutch set low.
- Pre-thread brass screws with a steel screw of the same size; brass is soft and snaps easily in hardwood.
- Choose the right metal outdoors. Stainless steel (316 for marine use) or silicon bronze resists corrosion; plain steel rusts and can stain the wood around it.
- Size down in thin stock. In teak trim under about 3/8 inch thick, a #4 or #6 screw, or glue alone, is often better than a #8.
